1080P 60Hz HDMI Extender Balun Over Ethernet (200ft.)

Regular price $54.69

Shipping calculated at checkout

  • ✅ Up To 1080P@60Hz Resolution Support: HDMI 1.4 and HDCP 1.4 compliant. Supports up to full HD 1080P@60Hz resolution and refresh rate, while also support previous resolutions such as 720P.
  • ✅ Long Distance Signal Transmission: Extend your audio/video HDMI signal up to 200ft. over a single Cat5e/6 ethernet cable without any latency.
  • ✅ Supports EDID Copy Function: Use the EDID copy function on the transmitter to help with audio and video signal incompatibility issues between the source and display. Also supports digital audio formats, such as Dolby Digital, if EDID is copied from the right device.
  • ✅ Optimal Performance: For better picture quality and longer distance transfer, we recommend to use Cat 6 or Cat 7 cable. For better performance, we suggest using solid copper ethernet cable with this product. For guaranteed optimal performance, use the J-Tech Digital Customized 150ft Cat6 Ethernet Cable. Please search the JTD-ID 943 on our website for more details.

Overnight shipping*:

Two days shipping:

Availability:
In stock
SKU:
JTD-146
Model:
JTD-HDEX-1

The JTDHDEX-1 HDMI over single ethernet extender is able to extend a 1080P 60Hz audio/video signal up to 150ft., which is four time the transmission distance of a typical HDMI cable. Enjoy deep color video and lossless compressed audio, and utilize the EDID copy function to eliminate any incompatibility issues that may occur within the setup. The JTDHDEX-1 is a great addition to an A/V distribution room, and it's easy installation make it perfect for any residential or commercial installation.

Transmission distance up to 150ft. over single ethernet cable. (For max distance, use Cat6/7 cable)

Supports Deep Color up to 36bits

Lossless compressed digital audio

Data transfer speed: 6.75Gbps

EDID copy function to avoid incompatibility issues

1080P HDMI extender balun over Ethernet up to 200ft
1080P 60Hz HDMI Extender Balun Over Ethernet (200ft.)

Specifications

General

Name Values
Operating Temperature Range -5 ~ 35°C (23 ~ 95°F)
Operating Humidity Range 5 - 90% RH non-condensing
Transmission Distance Up to 200ft. Over Single Cat5e/6
Power Consumption 5W (Max)
Dimensions (L x W x H) 83 x 48 x 25mm
Net Weight 250g (Pair)

Video

Name Values
Input Video Signal 5V p-p (TTL)
Resolution Up to 1080P 60Hz

Audio

Name Values
Audio Format Support
  • DTS-HD Master Audio
  • Dolby True-HD etc.

Resources & Downloads

Category Description Version File
MANUAL User Manual 1.0 jtd-146-user-manual-v1.0.pdf
COMPATIBILITY_CHART Phoenix Connectors 1.0 jtd-146-phoenix-connectors-v1.0.jpg

Category: MANUAL

Description: User Manual

Version: 1.0

File: jtd-146-user-manual-v1.0.pdf

Category: COMPATIBILITY_CHART

Description: Phoenix Connectors

Version: 1.0

File: jtd-146-phoenix-connectors-v1.0.jpg
