- ✅ 4-Input 2-Output HDMI Matrix | Up to 8K@60Hz/4K@120Hz Resolution: Connect up to 4 HDMI sources with resolutions up to 8K@60Hz or 4K@120Hz to 2 different displays. Supports HDMI 2.1, HDCP 2.3, HDR10/Dolby Vision to give you the best quality experience for your content
- ✅ Audio Extraction & ARC Function: Utilize the audio extraction feature to send 2Ch, 5.1Ch, or thru audio to an external audio system via SPDIF Optical or RCA. ARC feature allows you to send audio from an ARC compatible display back to the matrix for extraction via Optical. Note: While using ARC feature, you can only extract audio via Optical and not RCA. Only Output B supports ARC function
- ✅ Audio EDID Mode Selector: Switch between three audio EDID modes: Pass/2Ch/5.1Ch. Easily set the EDID mode according to the incoming audio format from the source for compatibility. Supports audio formats such as Dolby HD, DTS-HD, Dolby Atmos, Dolby AC3, DTS, LPCM
-
✅ Wide Resolution Compatibility: Supports resolutions such as 480P, 720P, 1080P, 2160P @ 24/25/30/50/60/100/120Hz. Supports 8K resolution @ 50/60Hz. 8/10/12/16Bit Color Depth supported at 2160P & 8/10Bit Color Depth supported at 4320P.
Note: In Matrix mode, one output can display 8K while the other output will display 4K. Unit won’t display 8K outputs simultaneously
